• Semi-welded Plate Heat Exchanger
Name:Semi-welded Plate Heat Exchanger
Type:Semi-welded plate/gasket type
Plate Material:Stainless Steel 304, 316L , 904L, SMO254, Titanium, HC276
Plate Thickness:0.5mm+1.0mm
Gasket Material:NBR, EPDM, HNBR, Viton/FKM, CR
Frame Material:Carbon steel , Stainless steel
Design Pressure:0-25bar
Design Temperature:-20~200℃

Product Description

Working Principle


The semi welded plate heat exchanger is composed of a pair of plates, and each of the two plates is laser welded to form a pair of plates. It is sandwiched between the fixed pressing plate and the movable pressing plate in a superimposed manner. The mesh contacts are formed between adjacent plates and supported by each other, and the rigidity of the plates is remarkably enhanced. Our semi welded plate heat exchanger adopts advanced laser welding technology, which has the advantages of small welding deformation, small residual stress and high quality.
